Marble Texture Printed PPGI Steel Coil NG4

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

PE (Polyester): Offers a cost-effective option with good flexibility and weather resistance.
PVDF (Polyvinylidene Fluoride): Provides superior resistance to UV rays and harsh weather conditions, ensuring long-lasting performance.

Structure:
Top 2 Layers / Back 1 Layer: Ensures enhanced protection and durability with a focus on the visible top side while maintaining adequate protection on the reverse side.

Applications:
Commonly used in construction for aesthetic and durable roofing, wall panels, and interior designs.
Suitable for various environments due to its corrosion-resistant properties and aesthetic appeal, mimicking the look of marble.
