PPGI PAINT

topcoat

Test

Result

Substrates

Hot dip galvanized

1

Product type

very high performance polyester

2

Color

E00*and E00 < 1 unit and also different in appearance mustn’ t be detectable with eye.

3

Viscosity

85±5s

4

Weight solid%

1210±40 kg/m3 variety after test to usemustn’ t be above 10 unit

5

Coverage

> 370 M2 /kg.μm

6

PMT

220-235 °c

7

T-bend

<2T

8

MEK rub Test

100 times (double)

9

Resin

Resin polyester modified with melamine

10

Salt spry test

500 hr

11

Solvent

500 hr

12

Pot life

At least 6 month in Temperature less than 35 °c

13

Fire Hazard

(flash point = 50degrees centigrade), 2B

14

UVA

2000 hr, after test gloss>50%-AE<3

15

Weight solid%

volume(63±2), weight(48±2) IS03251

16

Pencil hardness Test

minimum 1H

17

Impact Test

13 J , EN-13523-5, D2794

18

HCI Resistance

15% , 200-250 hr, with soak method
