PRINTED PPGI COIL SDJH017

Wooden / Marble / Flower designs are beautiful for decoration and making metal box and furniture, etc.

Details

PRODUCT INDEX

BASE MATERIAL	HDGI HDGL
THICKNESS	0.23-0.8mm
WIDTH	914-1250mm
INTERNAL DIAMETER	508mm
WEIGHT	3-7TON
PAINT	PE/PVDF
STRUCTURE	TOP 2/BACK 1

PERFORMANCE INDICATORS

TEST ITEM	TOP	BACK
PAINT THICKNESS	>5+18	5-7
GLOSSY	high 70±5/middle50土5/low30±5	35±5
COATING HARDNESS	≥H	≥H
T BELT	≤3T	≤4T
IMPACT RESISTANCE	≥9J	≥6J
DISSOLVENT RESISTANCE	≥100	≥50
SALT SPAY TEST	≥720hr
ACID RESISTANCE	SOAKED IN 5% HCL SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF
ALKALI RESISTANCE	SOAKED IN 5% NAOH SOLUTION FOR 300HR WHITHOUT BLISTERING, COLOR FADING AND COATING PEEL-OFF

The material of the coil can vary and it could be made of steel, aluminum, or other metals. The type of material used will depend on the intended application and the specific requirements of the project.Steel coils are the most common type of coils used for construction, they are relatively inexpensive and have good strength and durability. Aluminum coils are also commonly used, they are lightweight and have good corrosion resistance. They are often used in places where steel coils are not suitable due to weight restrictions. Other metals such as copper, brass, and titanium may also be used for specific applications where their unique properties are required.It is important to note that the choice of material will also affect the printing process, as different materials may require different printing techniques and coatings.
